Table 3.1: Ear Muff NRR Calculation Worksheet
Table 3.2: Earbud Mean Attenuation Levels
Frequency 125 250 500 1000 2000 3150 4000 6300 8000
Mean Attenuation 7.1 16.0 27.4 37.1 42.1 44.6 43.8 31.7 27.2
Earbud Deviation 1.8 1.1 1.4 2.1 1.7 1.7 2.4 0.2 0.1
1/3 octave
centerband
frequency
Assumed or
Measured
Sound levels
exterior to
Earmuff
C-weighting
response
correction
C-weighted
Sound Levels
Exterior to Ear
Muff or Plug
A-weighting
response
correction
A-weighted
Sound Levels
Exterior to Ear
Muff or Plug
Un-weighted
Attenuated
Levels of Ear
Muff or Plug
Standard
Deviation of
Attenuation
Standard
Deviation of
Attenuation
TIMES 2
Estimated
Projected A-
weighted
Levels inside
Ear Muff or
Plug
125
99.2 -0.2 99.0 -16.1 83.1 7.1 1.8 3.6 79.6
250
92.8 0.0 92.8 -8.6 84.2 16.0 1.1 2.1 70.3
500
93.7 0.0 93.7 -3.2 90.5 27.4 1.4 2.9 65.9
1000
94.9 0.0 94.9 0.0 94.9 37.1 2.1 4.2 62.0
2000
96.1 -0.2 95.9 1.2 97.3 42.1 1.7 3.4 58.5
3150
95.8 -0.5 95.3 1.2 97.0 44.6 1.7
4000
94.6 -0.8 93.8 1.0 95.6 43.8 2.4
4.0
55.8
6300
78.2 -2.0 76.2 -0.1 78.1 31.7 0.2
8000
78.4 -3.0 75.4 -1.1 77.3 27.2 0.1
0.3
50.4
Overall C Level 104.0 Overall A Level 80.3
NRR Calc
Overall C Level 104.0
Overall A Level 80.3
