Chapter 3
Applications
The following sections describe typical applications for the Cajun P330 in a network
with other Cajun Campus products.
Application 1
This application shows Cajun P550 as the network backbone with Cajun P330
stacks as closet devices with LAG and redundant links.
Figure 3.1 Cajun P330 stacks with a Cajun P550 Backbone
Cajun P550
Cajun P330 Cajun P330
10/100 Mbps Ethernet
10/100 Mbps Ethernet
10/100 Mbps Ethernet
Gigabit Ethernet
with LAG
Redundant
LAG
100 Mbps
Ethernet
(Fiber) with
LAG
Gigabit Ethernet
with LAG
4x100 Mbps
LAG
4x100 Mbps
LAG
