Chapter 4 Installation and Setup
Cajun P333T User’s Guide 21
Appropriate cables are available from your local supplier.
*1000BASE-LX over Multimode fiber requires a special Patch cord cable which you
can obtain from your local cable supplier.
Connecting to the Serial Port
Cajun P333T has one serial port on the front of the switch for connecting a
terminal, a terminal emulator, or a modem using the supplied adapter.
Note:
Modem connection requires a modem adapter which is supplied by Lucent
upon request.
The RJ-45 port on the front of the switch is labeled “Console”, and may be used to
configure the switch using the built-in Command Line Interface (CLI, Terminal
Emulation). In the future, this connector will also be used for out-of-band SNMP
management, via a modem.
The port settings are as follows:
• Baud Rate - 9600 bps
• Character Size - 8
•Parity - None
• Stop Bit - 1
• Flow Control - None
• We recommend using a VT-100 terminal to enable access to all CLI features.
The terminal connected to the serial port must be configured with the same
settings; this setting will work with any PC COM port over a DB9 to RJ45
connector.
Table 4.3 Gigabit Ethernet Cabling
Gigabit Interface Fiber Type
Diameter
(
µ
m)
Modal
Bandwidth
Maximum
Distance (m)
1000BASE-SX MM 62.5 160 220
1000BASE-SX MM 62.5 200 275
1000BASE-SX MM 50 400 500
1000BASE-SX MM 50 500 550
1000BASE-LX MM 62.5 500 550
1000BASE-LX MM 50 500 550
1000BASE-LX SM 9 NA 5,000
1000BASE-SLX SM 9 NA 10,000
