Application 2
This application shows a Cajun P330 stack forming the backbone of a Small/
Medium-sized Enterprise (SME) network with CajunP330 stacks as closet devices
with LAN and redundant links.
Figure 3.2 Cajun P330 stacks with a Cajun 330 backbone
Cajun P330
10/100 Mbps Ethernet
10/100 Mbps Ethernet
10/100 Mbps Ethernet
Gigabit Ethernet
with LAG
4x100 Mbps
LAG
4x100 Mbps
LAG
Cajun P330
Gigabit Ethernet
with LAG
LAG
Redundancy
