CALLMASTER Voice Terminals
13-8
13
The CALLMASTER IV set also has six call appearance/feature buttons, each with
a red and green light, and 15 feature-only buttons, each with a green status light.
At the bottom of the CALLMASTER IV is a MUTE button, a LOG IN and
RELEASE button used for processing ACD calls.
The CALLMASTER V is very similar to the 6416D+ telephone, since it can only be
used in a 2-wire environment, has 16 call appearance/feature buttons, and has a
display with softkeys and display control buttons with which the user can access
other features besides those administered on feature buttons. These telephones
also have six standard fixed feature buttons: a SPEAKER button, which can
access a one-way, listen-only speakerphone, MUTE button to mute the handset, a
red HOLD button, REDIAL button, TRANSFER/TEST button for transferring a call
or testing the lights and display on the telephone, and a CONF/RING button for
setting up a conference call and for selecting a personalized ringing pattern.
These telephones also have a red Message light and a Volume control button.
The CALLMASTER VI is a miniature voice terminal which has two call
appearance buttons with a red and green light beside each button, three feature
buttons, two of which have an associated green light, a MUTE button and a
HEADSET ON/OFF button which share a red light, and a blue RELEASE button.
Other features can also be used according to the software application on the PC.
On each of the two sides of the 602 CALLMASTER, the CALLMASTER II,
CALLMASTER III, CALLMASTER IV, and CALLMASTER VI, there is a headset
jack in which you can plug in a headset or, if special adapters are used, a handset.
(The CALLMASTER V also has a headset jack; however, it is located on the
bottom of the set.)
On the rear of the 602 CALLMASTER, there is a jack for an optional kneewall
adapter. You can plug two headsets or two handsets into this adapter. (Both
headsets or handsets must be the same model.)
Applications
The 602 CALLMASTER can be used with the DEFINITY Communications System
Generic 1, Generic 2, and Generic 3, the DEFINITY ECS, System 75 (R1V3 or
later), and System 85 (R2V2 or later).
The 603 voice terminals, which include the CALLMASTER II, CALLMASTER III,
and CALLMASTER IV, can be used only with a DEFINITY ECS G3V3 and later.
The CALLMASTER V and CALLMASTER VI work only with a DEFINITY ECS
Release 6.1. These voice terminals are especially suitable for Call Management
or ACD call-handling positions.
