Overview 3 C-LAN Administration
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
56
Configurations
The task descriptions are presented in six relatively simple configurations. Each
configuration describes how to administer either a 2-switch connection or a 3-switch
gateway connection. The procedures for administering these configurations can be
used either individually or in groups as “building blocks” for constructing most
networks involving DEFINITY ECS R8 and pre-R7 switches.
The following table lists the configurations described in this chapter.
The first 2 configurations are simple 2-switch networks. The next two are 3-switch
networks with Switch 1 serving as a gateway between different signaling types for
connection 1 and connection 2. The last two configurations are ppp–ethernet
networks; 5B, is the same as 5A except the Switch 1 has two C-LAN boards instead
of one.
10 Signaling group administered
~ page 1 — Trunk board address and Interface ID
~ Page 2 — Administered NCA TSC assignment
11 Synchronization plan administered
12 Trunk groups assigned
13 Dial plan administered
14 Uniform dial plan administered
15 AAR analysis administered
16 Route pattern administered
17 Hunt groups assigned
✔ Checklist Item
3 of 3
Config-
uration
Switch
2
Connection
1
Switch
1
Connection
2
Switch
3
Page
1 R7si ppp R7r page 60
2 R7csi ethernet R7r
(+CMS)
page 73
3 si bx.25 R7r ethernet R7si page 99
4 csi isdn R7si ppp R7csi page 124
5A R7csi ppp R7r ethernet R7si page 146
5B R7csi ppp R7r
(2 C-LAN
boards)
ethernet R7si page 171
