H.323 Trunk Administration
45
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
2 H.323 Trunks
Task 5 — Create a trunk group
This task creates a new trunk group for H.323 trunks. Each H.323 trunk must be a
member of an ISDN trunk group and must be associated with an H.323 signaling
group.
Note: The following steps address only those fields that are specifically related
to H.323 trunks. The other fields are administered as for previous releases
and are described in the Administrator’s Guide.
Begin
Task 5 Steps
> Open new Trunk Group form — enter a tr n
> Enter values
add trunk-group n Page 1 of 10
TRUNK GROUP
Group Number: 3 Group Type: isdn CDR Reports: y
Group Name: TG 3 for H.323 trunks COR: 1 TN: 1 TAC: 103
Direction: two-way Outgoing Display? n Carrier Medium: IP
Dial Access? n Busy Threshold: 99 Night Service:
Queue Length: 0
Service Type: tie Auth Code? n TestCall ITC: rest
Far End Test Line No:
TestCall BCC: 0
TRUNK PARAMETERS
Codeset to Send Display: 0 Codeset to Send National IEs: 6
Max Message Size to Send: 260 Charge Advice: none
Supplementary Service Protocol: a Digit Handling (in/out): enbloc/enbloc
Trunk Hunt: cyclical QSIG Value-Added Lucent? n
Digital Loss Group: 13
Calling Number - Delete: Insert: Numbering Format:
Bit Rate: 1200 Synchronization: async Duplex: full
Disconnect Supervision - In? y Out? n
Answer Supervision Timeout: 0
Field Conditions/Comments
Group Type Enter isdn.
Carrier Medium Enter ip.
Service Type Enter tie.
TestCall ITC: Enter unre (unrestricted).
TestCall BCC: Enter 0.
Codeset to Send Display Enter 0.
Note: Outgoing Display This field may need to be changed if the
far-end is a non-DEFINITY switch.
