H.323 Trunk Administration 2 H.323 Trunks
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
40
Task 2 — Define IP Interfaces
The IP interface for each C-LAN and MedPro board on the switch must be defined on
the IP Interfaces form. Each DEFINITY switch in an IP network has one IP Interfaces
form.
Begin
Task 2 Steps
> Open IP Interfaces form — enter ch ip-i
> Enter values
change ip-interfaces Page 1 of 2
IP Interfaces
Inter-region IP connectivity allowed? n
Enable Net
Eth Pt Type Slot Code Sfx Node Name Subnet Mask Gateway Addr Rgn
y C-LAN 01A10 TN799 B clan-a1 255.255.255.0 192.168.10 .100 1
y MEDPRO 01A13 TN802 B medpro-a1 255.255.255.0 192.168.10 .100 1
y MEDPRO 01A16 TN802 B medpro-a2 255.255.255.0 192.168.20 .100 1
y C-LAN 01A09 TN799 B clan-a2 255.255.255.0 192.168.20 .100 2
y MEDPRO 01B13 TN802 B medpro-a3 255.255.255.0 192.168.10 .100 2
y MEDPRO 01B09 TN802 B medpro-b1 255.255.255.0 192.168.10 .100 2
n 255.255.255.0 . . .
Field Conditions/Comments
Inter-region IP
connectivity
allowed?
Enter y to allow IP endpoints (phones and trunks) to use
MedPro resources administered in regions that are
different from the endpoints’ regions.
Enable Eth Pt The Ethernet port must be enabled (y) before it can be
used. The port must be disabled (n) before changes can be
made to its attributes on this screen.
Type Enter c-lan or medpro.
Slot Enter the slot location for the circuit pack.
Code Display only. This field is automatically populated with
TN799 for C-LAN or TN802 for MedPro.
Sfx Display only. This field is automatically populated with B
for the TN802 and TN799.
Node name Enter the unique node name for the IP interface. The node
name entered here must already be administered on the
Node Names screen
1 of 2
