H.323 Trunk Administration
39
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
2 H.323 Trunks
Begin
Task 1 Steps
> Open Node Names screen — enter ch node-n
> Go to page 2 of the screen
> Enter values.
> Submit the screen
End
change node-names Page 2 of 6
NODE NAMES
Name IP Address Name IP Address
clan-a1
______ 192.168.10_.31_ ___________ ___.___.___.___
clan-a2______ 192.168.20_.31_ ___________ ___.___.___.___
default 0 .0 .0 .0 ___________ ___.___.___.___
medpro-a1
___ 192.168.10_.81_ ___________ ___.___.___.___
medpro-a2___ 192.168.20_.81_ ___________ ___.___.___.___
medpro-a3
___ 192.168.10_.82_ ___________ ___.___.___.___
medpro-b1
___ 192.168.10_.83_ ___________ ___.___.___.___
___ ___.___.___.___ ___________ ___.___.___.___
Field Conditions/Comments
Name Enter unique node names for:
• Each C-LAN ethernet port on the network
• Each IP-Interface (Medpro) board on the local switch.
The default node name and IP address is used to set up a default
gateway, if desired. This entry is automatically present on the Node
Names screen and cannot be removed.
When the Node Names screen is saved, the system automatically
alphabetizes the entries by node name.
IP Address Enter a unique IP addresses for each node named in the previous
field.
