Index O
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
498
node names
example
218, 238
node names screen 245
node names, assign 38
node number routing screen 302
nonattendant consoles 342
noncall associated–temporary signaling connections
(NCA–TSC)
321, 369
NT administration, IP Trunk 426
O
Off-Premises Station feature
interactions
QSIG Message Waiting Indication
384
ones density 478
outgoing trunk queueing 383
P
PBX 488
configuring
DEFINITY ECS
421
performance, processor 412
ping, see utility programs, ping
pinouts, C-LAN
416
placing
IP trunk test calls
440
prerequisite administration, checklist 54
Private Network Access feature 348–349
forms 348
interactions
Attendant Call Waiting
349
Attendant Intrusion (Call Offer) 349
Private Networking features
Centralized Attendant Service (CAS)
338
DCS Alphanumeric Display for Terminals 313
DCS Attendant Control of Trunk Group Access 313
DCS Attendant Direct Trunk Group Selection 313
DCS Attendant Display 313
DCS Automatic Callback (ACB) 314
DCS Automatic Circuit Assurance (ACA) 314
DCS Busy Verification of Terminals and Trunks 314
DCS Call Coverage 315
DCS Call Forwarding 317
DCS Call Waiting 317
DCS Distinctive Ringing 317
DCS Leave Word Calling (LWC) 317
DCS Multiappearance Conference/Transfer 318
DCS Over ISDN–PRI D-Channel (DCS+) 320
DCS Trunk Group Busy/Warning Indication 318
Distributed Communications System (DCS) 312
Enhanced DCS (EDCS) 319
Extended Trunk Access (ETA) 344
Private Networking features, (continued)
Extension Number Portability (ENP)
346
Inter-PBX Attendant Service (IAS) 347
Italian DCS Protocol DCS 319
Private Network Access 348
QSIG Additional Network Feature Path Replacement
(ANF-PR)
367
QSIG Call Forwarding (Diversion) 362, 368
QSIG Call Transfer 362
QSIG Name and Number Identification 361
See also QSIG features
Uniform Dial Plan (UDP)
350
processor channel Assignment
example
239
processor channel assignment
example
221, 226
processor channels
enable
72
per system 10
processor performance 412
proxy ARP 27
Q
Q-reference points 360
QSIG Additional Network Feature Path Replacement
(ANF–PR) feature
367
interactions
Basic Call Management System (BCMS)
380
Call Detail Recording (CDR) 380
Call Management System (CMS) 380
Call Vectoring 380
Data Call Setup 381
Data Privacy 381
Data Restriction 381
Malicious Call Trace (MCT) 381
QSIG Call Transfer 380
Recorded Announcement 381
trunk access codes (TAC) 381
Voice Terminal Display 381
QSIG Additional Network Feature–Transit Counter
(ANF–TC) feature
361, 381
QSIG Call Forwarding (Diversion) feature
interactions
AAR and ARS 379
Alternate Facility Restriction Levels (AFRL) 379
Authorization Codes 379
Call Coverage 379
Call Detail Recording (CDR) 379
Call Forwarding 379
Distributed Communications System (DCS) 379
Facility Restriction Levels (FRL) and Traveling
Class Marks (TCM)
379
QSIG Name and Number Identification 379
terminating call has coverage active 379
Transfer 379
