E Index
495
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
Distributed Communications System (DCS) feature,
(continued)
AUDIX configuration examples 329
configuring DCS networks 312
DCS features 313
feature considerations 323
forms 293
interactions
Centralized Attendant Service (CAS)
342
Extension Number Portability (ENP) 347
QSIG Call Forwarding (Diversion) 379
QSIG Call Transfer 380
QSIG Name and Number Identification 380
Uniform Dial Plan (UDP) 354
network configurations 312
documents
how to order
xvi
dotted decimal notation 13
DS1 circuit pack
example
208, 228, 233
IP Trunk 421
DTGS buttons 342
E
E1 476
electronic tandem networks (ETN)
Private Network Access
349
ELMO xvi
Emergency Access to Attendant feature
interactions
Centralized Attendant Service (CAS) 342
enable
links
72
processor channels 72
Enhanced DCS (EDCS) feature 319, 324
interactions
Class of Restriction (COR)
329
DCS Call Waiting 327
DCS Multiappearance Conference/Transfer 329
enhanced private switched communications service
(EPSCS)
349
Erlang 410
error messages on IP trunks, viewing 442
ETA call screening table screen
screens
ETA call screenin table 298
Extended Trunk Access (ETA) feature 344–345
cautions 344
forms 344
interactions
Abbreviated Dialing (AD)
345
attendant calls 345
Data Call Setup 345
Extended Trunk Access (ETA) feature, interactions,
(continued)
Facility Restriction Levels (FRL) and Traveling
Class Marks (TCM)
345
Last Number Dialed 345
Modem Pooling 345
Remote Access 345
Extension Number Portability (ENP) feature 346
ENP codes 346
ENP numbering plans 346
interactions
Distributed Communications System (DCS)
347
Uniform Dial Plan (UDP) 354
extension number portability numbering plan screen
299
F
Facility Restriction Levels (FRL) and Traveling Class
Marks (TCM) features
interactions
Extended Trunk Access (ETA)
345
QSIG Call Forwarding (Diversion) 379
QSIG Message Waiting Indication 384
features. See Private Networking Features
fixing problems
IP trunks 443
G
gateway
default
22
IP routing 252
gateway nodes 322
Generalized Route Selection (GRS) feature
interactions
DCS Over ISDN–PRI D-Channel (DCS+) 328
QSIG Message Waiting Indication 384
Go to Cover feature
interactions
DCS Call Coverage 326
H
H.323 Trunk 7, 32
administration 33
signaling group 287
hardware
R7
7
High Density Bipolar 3-Bit Substitution (HDB3) 479
Hold feature
interactions
QSIG Supplementary Service - Call Completion
382
