465
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
Glossary
A AAR
See Automatic Alternate Routing (AAR).
Abbreviated Dialing (AD)
A feature that allows callers to place calls by dialing just one or two digits.
AD
See Abbreviated Dialing (AD)
ADU
See Asynchronous data unit (ADU).
adjunct
A processor that does one or more tasks for another processor and that is
optional in the configuration of the other processor. Intuity AUDIX and CentreVu
CMS are considered adjuncts to the DEFINITY ECS.
Administration Without Hardware (AWOH)
A feature that allows administration of ports without associated terminals or
other hardware.
ANSI
American National Standards Institute. A United States professional/technical
association supporting a variety of standards.
APLT
Advanced Private-Line Termination.
ARP
Address Resolution Protocol.
ARS
See Automatic Route Selection (ARS).
ASCII
American Standard Code for Information Interchange.
The standard code for
representing characters in digital form. Each character is represented by an
8-bit code (including parity bit).
