DCS over IP Trunk
437
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
F IP Trunk Installation and
Administration
On Switch A
On Switch B
On Switch C
These entries allow a specific line/port on the IP Trunk server to carry calls to a
specific other location. No digits are searched for, as we already know that the
DEFINITY has done the appropriate digit analysis. A unique string is applied in front
of each dialed string by adding a replace string; each replace string is unique to that
line/port, allowing for the terminating end to associate a call to the same line it left on
at the originating end.
Line Search
String
Replace
String
IP Address
1 None 01 198.152.169.236 (Switch C)
2 None 02 198.152.169.236 (Switch C)
3 None 03 198.152.169.236 (Switch C)
4 None 04 198.152.169.238 (Switch B)
5 None 05 198.152.169.238 (Switch B)
6 None 06 198.152.169.238 (Switch B)
Line Search
String
Replace
String
IP Address
4 None 04 198.152.169.240 (Switch A)
5 None 05 198.152.169.240 (Switch A)
6 None 06 198.152.169.240 (Switch A)
7 None 07 198.152.169.236 (Switch C)
8 None 08 198.152.169.236 (Switch C)
9 None 09 198.152.169.236 (Switch C)
Line Search
String
Replace
String
IP Address
1 None 01 198.152.169.240 (Switch A)
2 None 02 198.152.169.240 (Switch A)
3 None 03 198.152.169.240 (Switch A)
7 None 07 198.152.169.238 (Switch B)
8 None 08 198.152.169.238 (Switch B)
9 None 09 198.152.169.238 (Switch B)
