IP Trunk Administration
423
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
F IP Trunk Installation and
Administration
Note: Depending on how the routing between sites is administered, inserting
digits may be required. The example shows a "9" being inserted in front
of any digits received from the IP Trunk. In most DEFINITY ECS
switches, this is the access code for ARS and will allow the digits
received on the trunk to be analyzed and rerouted based on ARS analysis
table entries.
2 Enter the field values as shown in the screen diagram above.
Note: All IP trunk groups are administered as DS1 tie trunks (Group Type =
tie).
3 Move to the Trunk Features page and type n in the Maintenance Tests field.
4 In the Suppress # Outpulsing field, type y.
Note: You may need to fill in other fields for your system.
5 Move to the Group Member Assignments page and add the ports (channels)
you’ve purchased.
You’re assigning virtual ports, or channels, to the IP Trunk circuit pack. Each
channel can carry one call at a time. The number of ports you can use is limited to
the maximum number specified in your license.
TRUNK GROUP
Group Number: 5__ Group Type: tie CDR Reports: y
Group Name: IP Trunk 01A09 COR: 85_ TN: 1__ TAC: 105_
Direction: two-way_ Outgoing Display? y Trunk Signaling Type: ____
Dial Access? n Busy Threshold: 99_ Night Service: ____
Queue Length: 0__ Incoming Destination: ____
Comm Type: voice Auth Code? n
TRUNK PARAMETERS
Trunk Type (in/out): wink/wink___ Incoming Rotary Timeout(sec): 5_
Outgoing Dial Type: tone_____ Incoming Dial Type: tone____
Wink Timer (msec): 300 Disconnect Timing(msec): 500_
Digit Treatment: insertion Digits: 9___
Sig Bit Inversion: none
Connected to Toll? n STT Loss: low DTT to DCO Loss: normal
Incoming Dial Tone? y
Disconnect Supervision - In? y Out? n
Answer Supervision Timeout: 0__ Receive Answer Supervision? y
