Centralized Voice Mail Via Mode Code
397
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
B Private Networking
Setting Up Centralized Voice Mail Via Mode Code
The following step describe how to set up DEFINITY switches to support centralized
voice mail. For information on setting up Merlin Legend/Merlin Magix, see Merlin
Magix Integrated Systems Network Reference, 555-715-114. For information on
setting up
INTUITY Messaging Solutions, see INTUITY Messaging Solutions
Integration with System 75, Generic 1 and 3, and R5/6.
Begin
1 Enter change system-parameters customer-options on the command line
of your system administration screen.
2 On page 3, verify fields as follows:
~ ISDN-PRI
field is y.
~ Mode Code for Centralized Voice Mail?
field is y.
~ Mode Code Interface?
field is y.
~ UDP
field is y.
3 On the hub switch, enter add trunk group xxxx on the command line of your
system administration screen, where xxxx is the number of the ISDN-PRI trunk
group connecting the hub with the remote switch.
4 On page 1, verify fields as follows:
~ Group Type
field is ISDN.
~ Service Type
field is TIE.
5 On page 2, verify fields as follows:
~ Send Name field is y.
~ Send Calling Number field is y.
~ Numbering Format field is Private.
~ Send Connected Number field is y.
6 On each remote switch, repeat steps 3-5.
7 On each DEFINITY switch in the network, enter change dialplan on the
command line of your system administration screen.
8 Administer the dial plan for each node in the network (see Chapter 4 in this
document for examples). Usually the hub is considered Node 1.
If the network contains Merlin Legend/Magix systems:
~ Uniform Dialing Plan field is 4 for each node.
If the network contains only DEFINITY systems:
~ Uniform Dialing Plan field is 4 or 5.
9 For each DEFINITY node, enter change feature-access-codes on the
command line.
