QSIG
375
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
B Private Networking
Call Completion
In addition to the Basic QSIG Supplementary Services administration described
above, complete the following administration:
• On the Trunk Group screen, page 1, set the Supplementary Service Protocol field
to b and administer the trunk for Call Independent Signalling Connections.
Transfer into Voice Mail
In addition to the Basic QSIG Supplementary Services administration described
above, complete the following administration:
• On the System-Parameters Customer-Options screen, page 6, the Transfer Into
Lucent QSIG Voice Mail field must be set to y.
• On the Feature Access Code (FAC) screen, page 3, assign a Feature Access Code
in the Transfer to Voice Mail Access Code field. (This field is called “Transfer to
AUDIX Access Code” in pre-R8 systems).
• A hunt group must be in the coverage path of the user’s mailbox to be transferred
into, as administered on the Station and Coverage Path screens. On the hunt group
screen, page 2, for this hunt group, qsig-mwi must be entered in the Message
Center field and the number for the voice mail system must be entered in the Voice
Mail Number field.
Setting Up Centralized
Attendant Services
Begin
Steps
1
Enable QSIG Supplementary Services with Rerouting on the System Parameters
Customer Options screen, page 6, as described above.
2 On the System Parameters Customer Options screen, page 6, enter y in the
Centralized Attendant field.
3 On the Console Parameters screen, enter QSIG-main or QSIG-branch in the
CAS field.
a If QSIG-branch is entered in the CAS field, then enter a number for QSIG
CAS Number.
b If QSIG-branch is entered in the CAS field, then the field AAR/ARS Access
Code is optional.
4 Administer the QSIG ISDN trunk groups screen with option b for Supplementary
Service Protocol
5 Console Parameters screen.
6 Attendant Console screen.
7 Assign an extension to Attd on the Dial Plan Record screen at the main PBX.
8 Administer each QSIG Supplementary Service that will be used by attendants.
