Other Networking-Related DEFINITY Screens A Screens Reference
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
308
Ext Code, Type (and
associated data)
Displays what rules apply if the entries on the screen are not administered. For
example, shows a screen for Ext Codes starting with 512. If these entries are not
administered, the entry for Ext Code 51xxx applies to these entries, and if Ext Code
51xxx is not administered, the entry for Ext Code 5xxxx applies to these entries. In a
5-digit UDP, these read-only fields display only if at least 3 digits are specified in the
command-line key, although one set (the set on the left) of these fields would still
display if 2 digits are specified in the command-line key. If only 1 digit is specified or
if ’x’ or ’X’ is specified in the command-line key, then neither of these sets of fields
display, since there is no Ext Code more general than those listed on the screen.
dd Displays the two digits (or x’s) representing the extension or group of extensions to
be administered. For this field, "xx:" is repeated on both pages, since it is the default
for all other entries on both pages. Changing the type associated with this field on one
page changes it on both pages.
Valid entries Usage
AARCode
ENPNode
Local
TempOOS
UDPCode
blank
