Other Networking-Related DEFINITY Screens A Screens Reference
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
302
Node Number Routing
This screen specifies the routing pattern associated with each node in a public or private network. NNR is a
required capability for Extension Number Portability (ENP) and is associated with the Uniform Dial Plan (UDP).
Partitioned Group
Number
This read-only field displays the partitioned group number associated with the node
numbers being administered.
Node Number This display-only field lists the node number to be changed.
Route Pattern Enter the routing pattern associated with the corresponding node number. This field
repeats the same number of times as there are node numbers on the page.
change node-routing 87 partition 2 Page 1 of 2
NODE NUMBER ROUTING
Partitioned Group Number: 2
Route Route Route Route Route Route Route
Pat Pat Pat Pat Pat Pat Pat
15: ___ 30: ___ 45: ___ 60: ___ 75: ___ 90: ___
1: ___ 16: ___ 31: ___ 46: ___ 61: ___ 76: ___ 91: ___
2: ___ 17: ___ 32: ___ 47: ___ 62: ___ 77: ___ 92: ___
3: ___ 18: ___ 33: ___ 48: ___ 63: ___ 78: ___ 93: ___
4: ___ 19: ___ 34: ___ 49: ___ 64: ___ 79: ___ 94: ___
5: ___ 20: ___ 35: ___ 50: ___ 65: ___ 80: ___ 95: ___
6: ___ 21: ___ 36: ___ 51: ___ 66: ___ 81: ___ 96: ___
7: ___ 22: ___ 37: ___ 52: ___ 67: ___ 82: ___ 97: ___
8: ___ 23: ___ 38: ___ 53: ___ 68: ___ 83: ___ 98: ___
9: ___ 24: ___ 39: ___ 54: ___ 69: ___ 84: ___ 99: ___
10: ___ 25: ___ 40: ___ 55: ___ 70: ___ 85: ___
11: ___ 26: ___ 41: ___ 56: ___ 71: ___ 86: ___
12: ___ 27: ___ 42: ___ 57: ___ 72: ___ 87: ___
13: ___ 28: ___ 43: ___ 58: ___ 73: ___ 88: ___
14: ___ 29: ___ 44: ___ 59: ___ 74: ___ 89: ___
Valid entries Usage
Read-only field The partitioned group number is either specified on the
command line or defaults to partitioned group number 1.
Valid entries Usage
Display-only
field
Two pages display simultaneously for a total of 200 nodes (100
per page). For example, entering change node-routing 87
displays nodes 1 through 199, and entering change
node-routing 151 displays nodes 100 through 299. However,
entering change node-routing 999 displays nodes 900
through 999 on one page.
Valid entries Usage
1 to 254
blank
