A Screens Reference
As-needed Inactivity Time-out (min)
The inactivity time-out for as-needed NCA-TSCs assigned in the Signaling Group.
An as-needed administered NCA-TSC staying inactive in this time period will be
removed from service.
TSC Index
Specifies the administered NCA-TSCs assigned.
Local Ext
Used to assign an extension on the switch to the administered NCA-TSC. The
extension cannot be previously assigned to another administered NCA-TSC, station,
or data module, and so on.
Enabled
Enables or disables the administered NCA-TSC.
Establish
Used to indicate the strategy for establishing this administered NCA-TSC.
Valid entries Usage
10 to 90
blank
Valid entries Usage
Display-only field. The administered NCA TSC index represents
one DCS or DCS AUDIX logical channel
connecting any two switches. The Index
number ranges from 1–64.
Valid entries Usage
An unassigned extension number.
blank
Valid entries Usage
y Enter y to enable the administered NCA-TSC.
n
Valid entries Usage
permanent An entry of permanent means that the administered
NCA-TSC can be established by either the near end or the far
end.
as-needed An entry of as-needed means the administered NCA-TSC
will be established the first time the administered NCA-TSC is
needed. It can be set up either by the near end or far end switch.
blank
