Networking Screens
277
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
A Screens Reference
Circuit Packs
This screen administers circuit packs to carrier slots before the circuit packs are
actually installed in the carrier or cabinet. This allows the system to be configured
(administered) when the circuit packs have not yet been physically inserted in their
appropriate slots. Before any voice terminals, attendant consoles, or trunks can be
administered in the system, the correct type of circuit pack must be installed in the
appropriate slot, or using the Circuit Pack screen, a circuit pack must be assigned to
the slot.
The Circuit Pack Administration screens do not have to be completed if the system
cabinet is equipped with the circuit packs at the time of administration. However, for
switch node carriers, these screens must be administered.
Note: For initial installation procedures, circuit packs should only be assigned
slots per the hardware Configuration Layout record (obtained from the
factory or Customer Services Support Organization). Arbitrarily
assigning circuit packs to slots should not be attempted because this
eventually requires (at the time of installation and test) realignment of the
circuit packs and reworking associated wiring to agree with the software
translations or new software translations to agree with the shipped
hardware configuration.
Note: Each page of the screen represents one carrier within the cabinet
specified on the command line. For G3si, all carriers and slots appear
even if they are not included in the actual hardware. This supports
reconfiguration.
Cabinet This field shows the cabinet number as entered on the command line.
Page 1 of X
CIRCUIT PACKS
Cabinet: __ Carrier: _
Cabinet Layout: ____________________ Carrier Type: _________________
Slot Code Sf Mode Name Slot Code Sf Mode Name
00: ______ _ 11: MEDPRO _ RESERVED-IP
01: ______ _ 12: MEDPRO _ RESERVED-IP
02: ______ _ 13: TN802_ B MAPD
03: ______ _ 14: ______ _
04: ______ _ 15: ______ _
05: ______ _ 16: ______ _
06: ______ _ 17: ______ _
07: ______ _ 18: ______ _
08: ______ _ 19: ______ _
09: ______ _ 20: ______ _
10: ______ _ 21: ______ _
’#’ indicates circuit pack conflict.
Valid entries Usage
Display-only field.
