A Screens Reference
Interface Link Identifies the physical link carrying this processor (virtual) channel.
Interface Chan Identifies the BX.25 virtual channel number or the TCP/IP listen port channel to carry
this processor (virtual) channel.
Destination Node Identifies the switch or adjunct at the far end of this link.
Valid entries Usage
1-25 (csi, si)
1-33 (r)
For the csi model, all links (up to 25) must be used for tcp/ip
connections.
For the si model, links numbered 1 through (4 times the number
of PI circuit packs) can be either x.25 or tcp/ip. The rest of the
links (up to 25) must be tcp/ip.
For the r model, links numbered 1 through (4 times the number
of PGATE circuit packs) can be either x.25 or tcp/ip. The rest
of the links (up to 33) must be tcp/ip.
Valid entries Usage
1-64 (x.25)
0, 5000-64500
(ethernet or ppp)
The channel number 0 means any available port can be used
(which will be automatically selected by the system).
For TCP/IP connections, the following values are
recommended:
• 5001 CMS (Appl. = mis)
• 5002 Intuity AUDIX (Appl. = audix)
• 5003 DCS (Appl. = dcs, not a gateway)
These three values should be reused for multiple
instances of these applications; for example, if there are
two Intuity AUDIX’s, use 5002 for both; or if there are
four DEFINITY ECS’s, use 5003 for all four. The
combination of Link, Interface Channel, and Mach ID
must be unique.
• 6000 + (Appl. = gtwy-tcp)
The Interface Channel number must be unique for the
gtwy-tcp and gateway application types.
Valid entries Usage
A node name previously
entered on the Node
Names screen or blank.
This must be a name entered on the Node Names screen.
For ppp connections, it must match the Destination
Node Name entered on the ppp Data Module screen.
