Networking Screens
273
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
A Screens Reference
Communication-Interface Processor Channel
Proc Chan Displays the BX.25 virtual channel number or the TCP/IP listen port channel to carry
this processor (virtual) channel.
Enable Type y to enable a processor channel. Type n (default) to disable a processor channel.
PROCESSOR CHANNEL ASSIGNMENT
Proc Gtwy Interface Destination Session Mach
Chan Enable Appl. To Mode Link/Chan Node Port Local/Remote ID
1: _ ________ _ __ _____ _________ 0____ ___ ___ __
2: _ ________ _ __ _____ _________ 0____ ___ ___ __
3: _ ________ _ __ _____ _________ 0____ ___ ___ __
4: _ ________ _ __ _____ _________ 0____ ___ ___ __
5: _ ________ _ __ _____ _________ 0____ ___ ___ __
6: _ ________ _ __ _____ _________ 0____ ___ ___ __
7: _ ________ _ __ _____ _________ 0____ ___ ___ __
8: _ ________ _ __ _____ _________ 0____ ___ ___ __
9: _ ________ _ __ _____ _________ 0____ ___ ___ __
10: _ ________ _ __ _____ _________ 0____ ___ ___ __
11: _ ________ _ __ _____ _________ 0____ ___ ___ __
12: _ ________ _ __ _____ _________ 0____ ___ ___ __
13: _ ________ _ __ _____ _________ 0____ ___ ___ __
14: _ ________ _ __ _____ _________ 0____ ___ ___ __
15: _ ________ _ __ _____ _________ 0____ ___ ___ __
16: _ ________ _ __ _____ _________ 0____ ___ ___ __
Valid entries Usage
1-128 (csi model)
1-256 (si model)
1-384 (r model)
Enter information about the processor channel in the row
corresponding to the processor channel number you want
to use. Any Processor Channel number can be used in the
range appropriate for the switch model.
For connections to adjuncts, processor channel numbers 1,
2, 3, etc. are typically used. For connections between
switches, it may be convenient to use processor channel
numbers that are indicative of the endpoints of the
connection. For example, processor channel 13 for a
connection between switch 1 and switch 3.
Valid entries Usage
y/n Enter y when assigning the processor channel. This field must
be set to n before you can change any of the processor channel
parameters.
