Establish Connection? Specifies whether this switch will be responsible for the call setup for this
connection.
Connected Data Module This in an information-only field. This field displays when the Destination Number
field is other than eia.
Connected To Specifies whether the connected device is dte or isn.
ITC Information Transfer Capability. This field is used to determine the type of
transmission facilities to be used for ISDN calls originating from this endpoint.
Displays when Communication Type is 56k-data, 64k-data, or Wideband.
Enter restricted (default) or unrestricted to indicate the type of transmission
facilities to be used for ISDN calls originated from this endpoint. The field does not
display for voice-only or BRI stations.
When adding an access endpoint with the ITC administered as unrestricted, its
associated port must be a channel of a DS1 circuit pack with zero code suppression
administered as b8zs. If the port is not a channel of a DS1 circuit pack with its zero
code suppression administered as b8zs, the end validation fails and the form
submission is rejected.
Valid
Entries
Data
Module
Types
Usage
y/n
Default
is n.
procr-intf
x.25
Enter y if the System is responsible for any part of the call
setup for the link defined by this data module.
If the physical link is through a pair of MPDMs or
MTDMs, then each switch terminating the link must set
up a connection between its Processor Interface Data
Module and MPDM/MTDM.
Enter the opposite value when administering the data
module for switch at the other end of the connection.
If the link is to be used for ISDN signaling, enter y.
Valid Entries Data Module
Types
Usage
no entries — information
only
procr-intf
x.25
Valid entries Data Module
Types
Usage
dte, isn pdm Displays only when Type is pdm and the
Destination Number is set to eia. Enter dte if
the data module is connected to Data
Terminal Equipment (DTE) or enter isn if
connected to an Information Systems
Network (ISN).
