A Screens Reference
Node Name The node name for the interface (C-LAN port) defined by this data module.
Destination Number This field specifies the destination of the link.
Used to enable access to the correct trunk group at the far end of the connection. This
is typically the trunk access code (TAC) plus the extension of data module on the far
end. If you use just the extension, then you must administer UDP and AAR route
patterns to access the correct trunk group.
Valid Entries Data
Module
Types
Usage
A name administered on the Node
Names Screen.
For a ppp data module, AUDIX
and MSA names listed on page 1
of the Node Names screen are not
allowed in this field — only
names listed on pages 2–6 of the
Node Names screen are valid.
ppp This name is associated with
an IP address of the port on the
Node Names screen.
Valid
Entries
Data
Module
Types
Usage
Extension
number or
TAC +
extension
number or
eia or
external
Leave blank
if Establish
Connection?
is set to n.
procr-intf
x.25
Used to enable access to the correct trunk group at the
far end of the connection. This is typically the trunk
access code (TAC) plus the extension of data module
on the far end. If you use just the extension, then you
must administer UDP and AAR route patterns to
access the correct trunk group.
If a trunk access code (TAC) is used, prepend the TAC
to the extension.
Enter eia (simplex system only) for ...
The Link field must be set to 1 for eia.
For the x.25 data module, to connect the Adjunct via
the cable on the back of the PGATE circuit pack, enter
external. If a value other than external is used, the
associated X.25 data module must have a baud rate of
switched.
This field can be left blank assuming the other side
will call it; however, it is preferable to put in the actual
digits of the other side and set the Establish
Connection field to n. This enables you to identify
which X.25 data module on the remote switch is
expected to call this data module.
