A Screens Reference
Port Seven characters to specify the port location for this data module in the format
NNCSSPP.
Link The communication interface link number associated to this data module.
Name Descriptive label for the data module.
COS Class of service. COS specifies a group of feature-access permissions of a group of
telephones.
Valid Entries Data Module
Types
Usage
NN = cabinet number:
• 01 – 44 (r model)
• 01 – 03 (si model)
• 01 (csi model)
C = carrier position: a – e
SS = slot number: 00 – 20
PP = port number: 01 – 16
ppp
ethernet
x.25
pdm
You can enter x in the Port field
to indicate that there is no
hardware associated with the port
assignment (Administration
Without Hardware).
Valid Entries Data Module
Types
Usage
• 1-33 r model
• 1–25 si model
• 1–25 csi model
ppp
ethernet
procr-intf
x.25
Indicates the interface link number that
connects to another node in a DCS
network, a Message Server, CMS, SDN
Gateway, or AUDIX.
Valid Entries Data Module
Types
Usage
0-27
alphanumeric
characters.
Default is
blank.
ppp
ethernet
procr-intf
x.25
pdm
This field is not used by the system software.
Enter a descriptive name for ease in
identifying the data module. The contents of
this field are displayed when the list data
module command is used.
Valid
Entries
Data Module
Types
Usage
0-15
Default is 1
ppp
procr-intf
pdm
The value for this fields will be specified by the
system administrator.
