A Screens Reference
IP Interfaces
Use the IP Interfaces screen to define an interface to the LAN from either the C-LAN
or MedPro circuit packs. The physical interface is port 17 on the C-LAN board and is
a network interface card on the MedPro. This screen specifies the IP address (via the
Node Names screen), subnet mask, default gateway address, and the network region
for each IP interface on the local DEFINITY ECS.
Note: The C-LAN and MedPro circuit packs must be administered on the
Circuit Packs screen before they can be administered on this screen.
Inter-region IP
connectivity allowed?
Specifies whether or not IP endpoints registered in one region can use media
processing resources (MedPro) in another region.
change ip-interfaces Page 1 of 2
IP Interfaces
Inter-region IP connectivity allowed? n
Enable Net
Eth Pt Type Slot Code Sfx Node Name Subnet Mask Gateway Addr Rgn
y C-LAN 01A10 TN799 B clan-a1 255.255.255.0 192.168.10 .100 1
y MEDPRO 01A13 TN802 B med-a1 255.255.255.0 192.168.10 .100 1
y MEDPRO 01A16 TN802 B med-a2 255.255.255.0 192.168.20 .100 1
y C-LAN 01A09 TN799 B clan-a2 255.255.255.0 192.168.10 .100 2
y MEDPRO 01B13 TN802 B med-a3 255.255.255.0 192.168.10 .100 2
y C-LAN 01A09 TN799 B clan-b2 255.255.255.0 192.168.20 .100 2
n 255.255.255.0 . . .
n 255.255.255.0 . . .
n 255.255.255.0 . . .
Valid Values Usage
y/n Enter y to allow IP endpoints (phones and trunks) to use
MedPro resources administered in regions that are different
from the endpoints’ regions.
The MedPro and C-LAN boards are assigned to the regions
specified in the Net Rgn field. Endpoints are assigned to the
same region as the C-LAN boards they use.
The DEFINITY system first allocates MedPro resources that
are assigned to the same regions as the endpoints. If demand
for MedPro resources exceeds supply within the local region,
available MedPro resources from other regions are used if this
field is set to y, or call blockage occurs if this field is set to n.
