Network Map
207
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
4 Networking Example
Network Map
The network map shows the RNX, trunk group, hunt group numbers, data module type, and extension for each
Switch Node in the network. For TCP/IP connections, the node name and IP address is shown for each node.
Ethernet
LAN
10BaseT
hub
cydfec9b KLC 101999
router
192.168.1.200
192.168.2.200
intuity
192.168.1.70
ethernet1
192.168.1.11
ppp41
192.168.1.41
ppp14
192.168.1.14
Exts. 3000-3999
Exts. 2000-2999
Exts. 4000-4999
Exts. 1000-1999
cms
192.168.2.90
Voice - ISDN
TG 13
TAC 713
Voice
TG 12
TAC 712
Voice
TG 14
TAC 714
PPP Data
TG 24
TAC 724
BX.25 Data
TG 22
TAC 722
CMS
Intuity
AUDIX
Node 1
R8r Gateway
RNX 221
RNX 223
RNX 222
Node 3
R8si
Node 2
R6si
Node
R8csi
4
Ext.
1111
REM-AUDIX
HG 99
Ext. 3111
REM-AUDIX
HG 99
Ext. 2111
DS1
DS1
DS1
DS1
PGATE
PI
DTE
Ext. 1992
PI
DTE
Ext. 2992
Ext. 1191
C-LAN
C-LAN
Ext. 4991
7400D
RNX 224
DS1
DS1
REM-AUDIX
HG 99
Ext. 4111
Ext. 1194
