Configuration 5B: R8csi <—ppp—> R8r (2 C-LANs)
<—ethernet—> R8si
3 C-LAN Administration
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
200
Switch 3 Task — Assign Processor Channels
This task associates data links (hardware) with processor channels (software) on
Switch 3.
Begin
Steps
> Open the Processor Channel Assignment form — enter ch com p
> Enter values
change communications-interface processor-channels
Page 1 of X
PROCESSOR CHANNEL ASSIGNMENT
Proc Gtwy Interface Destination Session Mach
Chan Enable Appl. To Mode Link/Chan Node Port Local/Remote ID
1: n
_______ _ __ _____ _______ __ 0____ ___ ___ __
2: n
_______ _ __ _____ _______ __ 0____ ___ ___ __
3: n _______ _ __ _____ _______ __ 0____ ___ ___ __
4: n
_______ _ __ _____ _______ __ 0____ ___ ___ __
:
31: y
dcs ___ c 1_ 0 __ node-1b-eth 5003_ 31_13__ 1_
32: y dcs ___ s 1_ 5003_ node-2___ 0 32_23__ 2_
:
64: n _______ _ __ _____ _________ 0____ ___ ___ __
Field Conditions/Comments
Processor Channel 31: (ethernet connection to Switch 1)
Enable Set to y.
Appl. Set to dcs for DCS signaling.
Mode Node-3 is the "client" for this session. Set node-1 to "server" (s).
Interface Link This must match the link number assigned on the node-3 data
module screen.
Interface
Chan
A value of 0 allows any available interface channel to be used
for this connection. The Destination Port number on the
Switch-1 Processor Channel screen must also be set to 0.
Destination
Node
Name of the far-end node for this channel. This must be a name
entered on the Node Names screen.
Destination
Port
This number must match the Interface Channel number assigned
on the Switch-1 Processor Channel screen.
1 of 2
