Configuration 5A: R8csi <—ppp—> R8r (one C-LAN)
<—ethernet—> R8si
161
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
3 C-LAN Administration
Switch 2 Task — Assign Processor Channels
This task associates data links (hardware) with processor channels (software) on the
Switch 2.
Begin
Steps
> Open the Processor Channel Assignment form — enter ch com p
> Enter values
change communications-interface processor-channels
Page 1 of X
PROCESSOR CHANNEL ASSIGNMENT
Proc Gtwy Interface Destination Session Mach
Chan Enable Appl. To Mode Link/Chan Node Port Local/Remote ID
1: n
_______ _ __ _____ _____________ 0____ ___ ___ __
2: n
_______ _ __ _____ _____________ 0____ ___ ___ __
3: n _______ _ __ _____ _____________ 0____ ___ ___ __
4: n
_______ _ __ _____ _____________ 0____ ___ ___ __
:
21: y
dcs ___ c 1_ 0 _ node-1-ppp___ 5003_ 21_12_ 1_
23: y dcs ___ c 1_ 0 _ node-3_______ 5003_ 23_32_ 3_
:
64: n _______ _ __ _____ _____________ 0____ ___ ___ __
Field Conditions/Comments
For Processor Channel 21: (ppp connection to Switch 1)
Enable Set to y after the link administration is complete.
Appl. Set to dcs for DCS signaling.
Mode Node-2 is the “client” for this session. Set node-1-ppp on
Switch 1 to “server” (s).
Interface Link This must match the link number assigned on the node-2
data module screen.
Interface Chan A value of 0 allows any available interface channel to be
used for this connection. The Destination Port number on
the Switch-1 Processor Channel screen must also be set to
0.
Destination Node Name of the far-end node for this channel. This must be a
name entered on the Node Names screen. For ppp
connections, it must match the Destination Node Name
entered on the ppp Data Module screen.
Destination Port This number must match the Interface Channel number
assigned on the Switch-1 Processor Channel screen
1 of 2
