Configuration 4: R8csi <—ISDN—> R8si Gateway
<—ppp—> R8csi
143
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
3 C-LAN Administration
Switch 3 Task — Assign Processor Channels
This task associates data links (hardware) with processor channels (software) on
Switch 3.
Begin
Steps
> Open the Processor Channel Assignment form — enter ch com p.
> Enter values
change communications-interface processor-channels
Page 1 of X
PROCESSOR CHANNEL ASSIGNMENT
Proc Gtwy Interface Destination Session Mach
Chan Enable Appl. To Mode Link/Chan Node Port Local/Remote ID
1: n
_______ _ __ _____ _________ 0____ ___ ___ __
2: n
_______ _ __ _____ _________ 0____ ___ ___ __
:
31: y
dcs____ c 1_0 node-1___ 5003 31_ 13_ 1_
32: y
dcs____ c 1_0 node-1___ 6002 32_ 14_ 2_
:
64: n
_______ _ __ _____ _________ 0____ ___ ___ __
Field Conditions/Comments
Processor Channel 31: (ppp connection to Switch 1)
Enable Set to y.
Appl. Set to dcs for DCS signaling.
Mode Node-3 is the “client” for this session. Set node-1 to “server”
(s).
Interface Link This must match the link number assigned on the node-3 data
module screen.
Interface Chan A value of 0 allows any available interface channel to be used
for this connection. This number must match the Destination
Port number on the Switch-1 Processor Channel screen.
Destination
Node
Name of the far-end node for this channel. This must be a
name entered on the Node Names screen. For ppp
connections, it must match the Destination Node Name
entered on the ppp Data Module screen.
Destination Port This must match the Interface Channel number assigned on
the Switch-1 Processor Channel screen.
1 of 2
