Configuration 3: R8si<—x.25 —> R8r Gateway
<—ethernet—> R8si
3 C-LAN Administration
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
116
> Submit the screen
End
Session - Local The Local and Remote Session numbers can be any value
between 1 and 256 (si model) or 384 (r model), but they
must be consistent between endpoints. For each
connection, the Local Session number on this switch must
equal the Remote Session number on the remote switch and
vice versa.
It is allowed, and sometimes convenient, to use the same
number for the Local and Remote Session numbers. It is
allowed, but not recommended, to use the same Session
numbers for two or more connections.
Session - Remote
Mach ID Destination switch ID identified on the dial plan of the
destination switch. This is usually called the “node
number.”
Processor Channel 23: (connection to Switch 1 for gateway to Switch 3)
Enable Set to y.
Appl. Set to dcs for DCS signaling.
Mode Used for TCP/IP connections only.
Interface Link This must match the link number assigned on the procr-intf
data module screen.
Interface Chan The interface channel number must be in the range 1 – 64
for an X.25 link.
Destination Node Used for TCP/IP connections only.
Destination Port Used for TCP/IP connections only.
Session - Local For each connection, the Local Session number on this
switch must equal the Remote Session number on the
remote switch and vice versa.
Session - Remote
Mach ID Destination switch ID identified on the dial plan of the
destination switch.
Field Conditions/Comments
2 of 2
