Configuration 3: R8si<—x.25 —> R8r Gateway
<—ethernet—> R8si
3 C-LAN Administration
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
104
Switch 1 Task — Assign Link via x.25 Data Module to Switch 2
This task administers an x.25 data module for the connection to node 2. The data
module associates a link number with a port address and extension number for the
PGATE port used for this connection.
Begin
Steps
> If a PGATE circuit pack is not already administered in slot 1c01, insert the circuit
pack in the slot and enter add pgate 1c01, then fill in the PGATE screen.
>Open the Data Module form — enter a da n
> Enter values
add data-module next
Page 1 of 2
DATA MODULE
Data Extension: 2102 Name: x.25 on link 5 to sw-2
Type: x.25 COS: 1 Remote Loop-Around Test? n
Port: 01C0102 COR: 1 Destination Number: external
Baud Rate: 9600___ TN: 1 Establish Connection? y
Endpoint Type: adjunct DTE/DCE: dte Connected Data Module: 4121_
Link: 5
_ Enable Link? n Error Logging? n
Permanent Virtual Circuit? y Highest PVC Logical Channel: 64
Switched Virtual Circuit? n
Field Conditions/Comments
Type: This indicates the data-module type for this connection.
Port: This example means that the PGATE circuit pack is in slot
01c01 and link 5 uses port 02.
Baud Rate: Set to
9600 for DCS connections to vs or si models, or to an r
model with an external 9600 baud data line.
Set to
switched for r-to-r connections with common channel
signaling on DS1 trunks.
Set to 9600 for connections to Intuity AUDIX.
Set to either
9600 or 19200 for CMS, depending on the
physical connectivity.
Endpoint Type: For DCS, CMS, or Intuity AUDIX, set this field to
adjunct.
Link: The link number must be in the range 1 – 33 (for R8r), not
previously assigned on this switch.
1 of 2
