Configuration 2: R7r (+CMS) <—ethernet—> R7csi
95
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
3 C-LAN Administration
Administer Subscribers
Subscribers must be administered on the Intuity system. For more information on this,
see the Lucent I
NTUITY Messaging Solutions Release 5 documentation. The following
screens show examples of subscriber screens on the Intuity system.
add subscriber 3066 Page 1 of 2
SUBSCRIBER
Name: Jean Collins Locked? n
Extension: 150 Password:
COS: class00 Miscellaneous:
Switch Number: 1 Covering Extension: 161
Community ID: 1 Broadcast Mailbox? n
Secondary Ext:
Account Code:
add subscriber 3066 Page 2 of 2
SUBSCRIBER CLASS OF SERVICE PARAMETERS
Addressing Format: extension Login Announcement Set: System
System Multilingual is ON Call Answer Primary Annc. Set: System
Call Answer Language Choice? n Call Answer Secondary Annc. Set: System
PERMISSIONS
Type: call-answer Announcement Control? y Outcalling? n
Priority Messages? n Broadcast: none IMAPI Access? y
IMAPI Message Transfer? n Fax Creation? n Trusted Server Access? y
INCOMING MAILBOX Order: fifo Category Order: nuo
Retention Times (days), New: 10 Old: 10 Unopened: 10
OUTGOING MAILBOX Order: fifo Category Order: unfda
Retention Times(days), File Cab: 10 Delivered/Nondeliverable: 5
Voice Mail Message (seconds), Maximum Length: 300 Minimum Needed: 32
Call Answer Message (seconds), Maximum Length: 120 Minimum Needed: 8
End of Message Warning Time (seconds):
Maximum Mailing Lists: 25 Total Entries in all Lists: 250
Mailbox Size (seconds), Maximum: 3600 Minimum Guarantee: 0
