Digital Video Recorder User Manual
Appendix F 16-CH Specifications
Compression format H.264 Main Profile
Video output
Composite：1.0V p-p/75Ω BNC×2, VGAX1
Video Input
Composite：1.0V p-p/75Ω BNC×16
VGA Resolution 1280*1024 /1024*768/ 800*600
Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC)
Display Frame Rate 400FPS (PAL), 480FPS (NTSC)
Record Frame Rate 400/100FPS (PAL), 480/120FPS (NTSC)
Audio Input RCA X4
Audio output RCA X1
Alarm Input NO or NC 16CH
Alarm output: 1CH
Record Mode Manual / Sensor /Timer / Motion detection
Simplex/Duplex/Triplex Pentaplex
Network Interface RJ45 (LAN, INTERNET)
PTZ control YES
Communication interface RS485, USB2.0 x 2(one for backup, another for USB mouse)
Disk info SATA x 1+DVD-RW x 1 or SATA x 2
Remote controller YES
Power Supply 12V4A
Temperature
0℃-50℃
Humidity 10%-90%
Average Operating Power （Excluding HDD） ≤30W
