Cabling SCSI Devices 3-11
Figure 3.8 SCSI Cable – 68-Pin High Density with Termination
Figure 3.9 SCSI Cable – 68-Pin High Density without Termination
Figure 3.10 SCSI Cable – 50-Pin Low Density
3.3.2 External SCSI Cables and Connectors
All external SCSI bus connections to your Ultra160 SCSI host adapter
are made with shielded cables. Figures 3.11 through 3.13 provide
examples of external cables. The connectors on this cable are keyed to
ensure proper pin-1 connection. Refer to Figure 3.14 for examples of
connectors found on external SCSI cables.
Terminator
