2-10 Detailed Host Adapter Installation
The peripheral device SCSI IDs are usually set with jumpers or with a
switch on the peripheral. Refer to the peripheral manufacturer’s
instructions and to the user’s manual for your computer to determine the
ID of each device and how to change it. No duplication of SCSI IDs is
allowed on a SCSI bus. To set your SCSI IDs, follow these steps:
Step 1. Determine the SCSI ID of each device on the SCSI bus.
Step 2. Make any necessary changes to the SCSI IDs and record the
IDs for future reference. Correct any duplications at this time.
Table 2.1 provides a place to keep this record.
Table 2.1 SCSI ID Record
SCSI ID SCSI Device Channel A SCSI Device Channel B
15
14
13
12
11
10
9
8
7 Ultra160 SCSI to PCI
Host Adapter
Ultra160 SCSI to PCI
Host Adapter
6
5
4
3
2
1
0
