Logic PCI to Dual Channel SCSI Host Adapter User's Guide LSI21003

Operational Environment 3-11
Table 3.7 SCSI Connector J5, Channel B, Internal
Signal Name Pin Signal Name Pin Signal Name Pin
SD12+ 1 SACK+ 24 SD7− 47
SD13+ 2 SRST+ 25 SDP− 48
SD14+ 3 SMSG+ 26 GND 49
SD15+ 4 SSEL+ 27 GND 50
SDP1+ 5 SC_D+ 28 TERMPWR 51
SD0+ 6 SREQ+ 29 TERMPWR 52
SD1+ 7 SI_O+ 30 N/C 53
SD2+ 8 SD8+ 31 GND 54
SD3+ 9 SD9+ 32 SATN− 55
SD4+ 10 SD10+ 33 GND 56
SD5+ 11 SD11+ 34 SBSY− 57
SD6+ 12 SD12− 35 SACK− 58
SD7+ 13 SD13− 36 SRST− 59
SDP+ 14 SD14− 37 SMSG− 60
GND 15 SD15− 38 SSEL− 61
DIFFSENS 16 SDP1− 39 SC_D− 62
TERMPWR 17 SD0− 40 SREQ− 63
TERMPWR 18 SD1− 41 SI_O− 64
N/C 19 SD2− 42 SD8− 65
GND 20 SD3− 43 SD9− 66
SATN+ 21 SD4− 44 SD10− 67
GND 22 SD5− 45 SD11− 68
SBSY+ 23 SD6− 46
