Logic PCI to Dual Channel SCSI Host Adapter User's Guide LSI21003

3-6 Technical Specifications
Note: Shaded pins are not connected.
Table 3.3 PCI Connector J1 Back Side Signals
Signal Name Pin Signal Name Pin Signal Name Pin
TRST/ 1 AD28 22 PAR 43
+12 V 2 AD26 23 AD15 44
TMS 3 GND 24 +3.3 V 45
TDI 4 AD24 25 AD13 46
+5 V 5 IDSEL 26 AD11 47
INTA/ 6 +3.3 V 27 GND 48
INTC/ 7 AD22 28 AD09 49
+5 V 8 AD20 29 KEYWAY 50
RESERVED 9 GND 30 KEYWAY 51
Vio 10 AD18 31 C_BE0/ 52
RESERVED 11 AD16 32 +3.3 V 53
KEYWAY 12 +3.3 V 33 AD06 54
KEYWAY 13 FRAME/ 34 AD04 55
3.3 V AUX 14 GND 35 GND 56
RST/ 15 TRDY/ 36 AD02 57
Vio 16 GND 37 AD00 58
GNT/ 17 STOP/ 38 Vio 59
GND 18 +3.3 V 39
REQ64/ 60
PME 19 RESERVED 40 +5 V 61
AD30 20
RESERVED 41 +5 V 62
+3.3 V 21 GND 42
