Completing the Installation 2-25
2.5 Completing the Installation
Before replacing the cover on your computer, review this installation
procedure check list. This can save you effort later.
Step 1. Replace the cabinet cover on your computer.
Step 2. Plug in all power cords.
Step 3. Switch power on to all devices and to your computer.
Step 4. Wait for your computer to boot up.
Step 5. To change the configuration of the host adapter, refer to the PCI
Storage Device Management System SDMS 4.0 User’s Guide,
for information on the BIOS software and its operation.
Step 6. Load the software and drivers suitable to your application and
system.
Refer to the PCI Storage Device Management System
SDMS 4.0 User’s Guide or to the guide for the software you
plan to use.
Verify Installation Procedures Done
Host adapter connection in PCI bus slot secure
Internal SCSI bus connections secure (pin-1 continuity)
External SCSI bus connections secure
Proper SCSI bus termination established
Unique SCSI IDs set and recorded for each device
