4.13 ADVANCE MENU ___ BACKUP

Move the cursor to “BACKUP” and press ”ENTER”. The screen will show the following

options.

1) START TIME:

Select the start time of the backup.

2) END TIME:

Select the end time of the backup.

3) AVAILABLE SIZE:

Display the available capacity in the inserted USB flash drive.

4) CHANNEL:

Select channels by pressing “ENTER” button to change the symbol in front of the

channel number.

Symbol “X” means that this channel is not selected to backup.

Symbol “●” means that this channel is selected to backup.

5) HDD NUM:

Show the HDD from which you want to backup data.

6) BACKUP TO USB:

Press “ENTER” to start copying the chosen file to the USB flash drive.

7) Audio Backup:

For audio 1 backup, please choose CH1.

BACKUP

USB BACKUP

Select “USB BACKUP” and then press “Enter”.

NOTE:

c Please use PC to format the USB flash drive as "FAT 32".

d If the USB flash drive is not supported by the DVR, the “USB ERROR” message will

be shown on the screen.

e We recommend to clear all the files in the USB flash drive before you backup files in

your USB flash drive.

f The backup file can be played directly in your PC via the supplied licensed AP, or via

other media players (Ex: Windows Media Player or RealPlayer) after the file is

converted to “AVI” format. For detailed AP playback, please refer to P.36.

USB BACKUP

START TIME 2006-MAY-12 16 : 30 : 00

END TIME 2006-MAY-12 16 : 40 : 00

AVAILABLE SIZE 0512 MB

CHANNEL

● 01 X 02 X 03 X 04

HDD NUM HDD-MASTER-1

BACKUP TO USB START
