User's Manual
Table Of Contents
- Terminology
- Introduction
- Installation
- Software configuration
- Prepare your PC to configure the WLAN Broadband Router
- Connect to the WLAN Broadband Router
- Management and configuration on the WLAN Broadband Router
- Status
- Setup Wizard
- Operation Mode
- Wireless - Basic Settings
- Wireless - Advanced Settings
- Wireless - Security Setup
- Wireless - Access Control
- WDS Settings
- Site Survey
- WPS
- LAN Interface Setup
- WAN Interface Setup
- Firewall - Port Filtering
- Firewall - IP Filtering
- Firewall - MAC Filtering
- Firewall - Port Forwarding
- Firewall - URL Filtering
- Firewall - DMZ
- Management - Statistics
- Management - DDNS
- Management - Time Zone Setting
- Management - Denial-of-Service
- Management - Log
- Management - Upgrade Firmware
- Management - Save/ Reload Settings
- Management - Password Setup
- FREQUENTLY ASKED QUESTIONS (FAQ)
- What and how to find my PC’s IP and MAC address?
- What is Wireless LAN?
- What are ISM bands?
- How does wireless networking work?
- What is BSSID?
- What is ESSID?
- What are potential factors that may causes interference?
- What are the Open System and Shared Key authentications?
- What is WEP?
- What is Fragment Threshold?
- What is RTS (Request To Send) Threshold?
- What is Beacon Interval?
- What is Preamble Type?
- What is SSID Broadcast?
- What is Wi-Fi Protected Access (WPA)?
- What is WPA2?
- What is 802.1x Authentication?
- What is Temporal Key Integrity Protocol (TKIP)?
- What is Advanced Encryption Standard (AES)?
- What is Inter-Access Point Protocol (IAPP)?
- What is Wireless Distribution System (WDS)?
- What is Universal Plug and Play (uPNP)?
- What is Maximum Transmission Unit (MTU) Size?
- What is Clone MAC Address?
- What is DDNS?
- What is NTP Client?
- What is VPN?
- What is IPSEC?
- What is WLAN Block Relay Between Clients?
- What is WMM?
- What is WLAN ACK TIMEOUT?
- What is Modulation Coding Scheme (MCS)?
- What is Frame Aggregation?
- What is Guard Intervals (GI)?
- Configuration examples
Introduction
-7-
2.3 Product Features
Generic Router
Ø Compatible with IEEE 802.11n Draft 2.0 Specifications provides wireless speed up to 150Mbps
data rate.
Ø Compatible with IEEE 802.11g high rate standard to provide wireless Ethernet speeds of 54Mbps
data rate.
Ø Maximizes the performance and ideal for media-centric applications like streaming video, gaming
and Voice over IP technology.
Ø Supports multi-operation (bridge/gateway/WISP) modes between wireless and wired Ethernet
interfaces.
Ø Supports WPS, 64-bit and 128-bit WEP, WPA, WPA2 encryption/decryption and WPA with
Radius function to protect the wireless data transmission.
Ø Supports IEEE 802.1x Authentication.
Ø Supports IEEE 802.3x full duplex flow control on 10/100M Ethernet interface.
Ø Supports DHCP server to provide clients auto IP addresses assignment.
Ø Supports DHCP client, static IP, PPPoE, PPTP of WAN Interface.
Ø Supports firewall security with port filtering, IP filtering, MAC filtering, port forwarding, trigger port,
DMZ hosting and URL filtering functions.
Ø Supports WEB based management and configuration.
Ø Supports UPnP for automatic Internet access.
Ø Supports Dynamic DNS service.
Ø Supports NTP client service.
Ø Supports Log table and remote Log service.
Ø Support Setup Wizard mode.
