6.2 Example two - fixed IP on the WAN
Company ABC likes to establish a WLAN network to support mobile communication on all
employees’ Notebook PCs. MIS engineer collects information and plans the WLAN Broadband
Router implementation by the following configuration.
WAN configuration:Fixed IP
IP Address
192.168.2.254
Subnet Mask
255.255.255.0
Default Gateway
192.168.2.10
DNS Address
168.95.1.1
LAN configuration:
IP Address
192.168.1.254
Subnet Mask
255.255.255.0
Default Gateway
192.168.2.254
DHCP Client Range
192.168.1.100 – 192.168.1.200
