User's Manual
Table Of Contents
- Terminology
- Introduction
- Installation
- Software configuration
- Prepare your PC to configure the WLAN Broadband Router
- Connect to the WLAN Broadband Router
- Management and configuration on the WLAN Broadband Router
- Status
- Setup Wizard
- Operation Mode
- Wireless - Basic Settings
- Wireless - Advanced Settings
- Wireless - Security Setup
- Wireless - Access Control
- WDS Settings
- Site Survey
- WPS
- LAN Interface Setup
- WAN Interface Setup
- Firewall - Port Filtering
- Firewall - IP Filtering
- Firewall - MAC Filtering
- Firewall - Port Forwarding
- Firewall - URL Filtering
- Firewall - DMZ
- Management - Statistics
- Management - DDNS
- Management - Time Zone Setting
- Management - Denial-of-Service
- Management - Log
- Management - Upgrade Firmware
- Management - Save/ Reload Settings
- Management - Password Setup
- FREQUENTLY ASKED QUESTIONS (FAQ)
- What and how to find my PC’s IP and MAC address?
- What is Wireless LAN?
- What are ISM bands?
- How does wireless networking work?
- What is BSSID?
- What is ESSID?
- What are potential factors that may causes interference?
- What are the Open System and Shared Key authentications?
- What is WEP?
- What is Fragment Threshold?
- What is RTS (Request To Send) Threshold?
- What is Beacon Interval?
- What is Preamble Type?
- What is SSID Broadcast?
- What is Wi-Fi Protected Access (WPA)?
- What is WPA2?
- What is 802.1x Authentication?
- What is Temporal Key Integrity Protocol (TKIP)?
- What is Advanced Encryption Standard (AES)?
- What is Inter-Access Point Protocol (IAPP)?
- What is Wireless Distribution System (WDS)?
- What is Universal Plug and Play (uPNP)?
- What is Maximum Transmission Unit (MTU) Size?
- What is Clone MAC Address?
- What is DDNS?
- What is NTP Client?
- What is VPN?
- What is IPSEC?
- What is WLAN Block Relay Between Clients?
- What is WMM?
- What is WLAN ACK TIMEOUT?
- What is Modulation Coding Scheme (MCS)?
- What is Frame Aggregation?
- What is Guard Intervals (GI)?
- Configuration examples
FREQUENTLY ASKED QUESTIONS (FAQ)
-61-
6 Configuration examples
6.1 Example one - PPPoE on the WAN
Sales division of Company ABC likes to establish a WLAN network to support mobile
communication on sales’ Notebook PCs. MIS engineer collects information and plans the WLAN
Broadband Router implementation by the following configuration.
WAN configuration:PPPoE
User Name
84549386
Password
2uprlamv
Note:User Name and Password.ISP provide.
LAN configuration:
IP Address
192.168.1.254
Subnet Mask
255.255.255.0
Default Gateway
0.0.0.0
DHCP Client Range
192.168.1.100 – 192.168.1.200
WLAN configuration:
SSID
AP
Channel Number
11
1.
Configure the WAN interface:
Open WAN Interface Setup page, select PPPoE then enter the User Name “84549386” and
Password “2uprlamv”, the password is encrypted to display on the screen.
Press button to confirm the configuration setting.
