User's Manual

-6-
WEP
Wired Equivalent Privacy
WLAN
Wireless Local Area Network
WPA
Wi-Fi Protected Access
2 Introduction
The Wireless LAN Broadband Router is an affordable IEEE 802.11b/g with 802.11n Draft 2.0
specifications of wireless LAN broadband router solution; setting SOHO and enterprise standard for
high performance, secure, manageable and reliable WLAN. This document describes the steps
required for the initial IP address assign and other WLAN router configuration. The description
includes the implementation of the above steps.
2.1 Package contents
The package of the WLAN Broadband Router includes the following items,
ü The WLAN Broadband Router
ü The DC Power Adapter
ü The Documentation CD
ü RJ-45 Cable Line (Option)
ü The Cradle
ü The 2dbi antenna
2.2 Product Specifications
Product Name
WLAN 11n Router, 2.4G
Standard
802.11b/g/n(Wireless), 802.3(10BaseT), 802.3u(100BaseT)
Data Transfer Rate
1,2,5.5,6,9,11,12,18,24,36,48,54, and maximum of 150Mbps
Modulation Method
BPSK/QPSK/16-QAM/64-QAM
Frequency Band
2.4GHz - 2.483GJz ISM Band, DSSS
RF Output Power
< 14dBm(802.11n),< 17dBm(802.11b),< 15dBm(802.11g)
Receiver Sensitivity
802.11b: -80dBm@8%, 802.11g: -70dBm@10%,
802.11n: -64dBm@10%
Operation Range
Indoor@Up to 100 meters,Outdoor@Up to 280 meters
Antenna
External Antenna(1Tx1R)
LED
Power, Active (WLAN), Act/Link (Ethernet)
Security
64 bit/128 bit WEP, TKIP, AES
LAN interface
One 10/100BaseT with RJ45 connector (WAN)
Four 10/100BaseT with RJ45 connectors (LAN)
Power Consumption
12 V, 1A Power Adapter
Operating
Temperature
0 ~ 50°C ambient temperature
Storage Temperature
-20 ~ 70°C ambient temperature
Humidity
5 to 90 % maximum (non-condensing)
Dimension
146 x 100 x 24 mm
