Software configuration
-45-
Item
Description
Enable Port
Forwarding
Click to enable the Port Forwarding security function.
Local IP Address
Protocol Port Range
Comment
To forward data packets coming from WAN to a
specific IP address that hosted in local network
behind the NAT firewall, fill in the IP address,
protocol, port range and your comments.
The Protocol can be TCP, UDP or Both.
The Port Range for data transmission.
Comments let you know about whys to allow data
packets forward to the IP address and port number.
Apply Changes
Click the Apply Changes button to register the IP
address and port number to Port forwarding list.
Reset
Click the Reset button to abort change and recover
the previous configuration setting.
Delete Selected
Click to delete the selected IP address and port
number that will be removed from the port-forwarding
list.
Delete All
Click to delete all the registered entries from the
port-forwarding list.
Reset
Click the Reset button to abort change and recover
the previous configuration setting.
