User's Manual

Software configuration
-37-
User Name
If you select the PPPoE support on WAN
interface, fill in the user name and password
to login the PPPoE server.
Password
If you select the PPPoE support on WAN
interface, fill in the user name and password
to login the PPPoE server.
Service Name
Fill in the service name of Service Name. The
default value is empty.
Connection Type
Select the connection type from pull-down
menu. There are Continuous, Connect on
Demand and Manual three types to select.
Continuous connection type means to setup
the connection through PPPoE protocol
whenever this WLAN AP Router is powered
on.
Connect on Demand connection type
means to setup the connection through
PPPoE protocol whenever you send the data
packets out through the WAN interface; there
are a watchdog implemented to close the
PPPoE connection while there are no data
sent out longer than the idle time set.
Manual connection type means to setup the
connection through the PPPoE protocol by
clicking the Connect button manually, and
clicking the Disconnect button manually.
Idle Time
If you select the PPPoE and Connect on
Demand connection type, fill in the idle time
for auto-disconnect function. Value can be
between 1 and 1000 minutes.
MTU Size
Fill in the mtu size of MTU Size. The default
value is 1400.
Attain DNS Automatically
Click to select getting DNS address for
DHCP support.
Please select Set DNS Manually if the
DHCP support is selected.
Set DNS Manually
Click to select getting DNS address for
DHCP support.
DNS 1
Fill in the IP address of Domain Name Server
1.
DNS 2
Fill in the IP address of Domain Name Server
2.
DNS 3
Fill in the IP address of Domain Name Server
3.
Clone MAC Address
Fill in the MAC address that is the MAC
