Item
Description
Disable Wireless LAN Interface
Click on to disable the wireless LAN data transmission.
Band
Click to select 2.4GHz(B) / 2.4GHz(G) / 2.4GHz(N) /
2.4GHz(B+G)/ 2.4GHz(G+N) / 2.4GHz(B+G+N)
Mode
Click to select the WLAN AP / Client / WDS /
AP+WDS wireless mode.
Network Type
While Mode is selected to be Client. Click to select the
network type infrastructure or Ad hoc.
SSID
It is the wireless network name. The SSID can be 32
bytes long.
Channel Width
Select the operating channel width 20 MHz or 40 MHz.
[N band only]
Control Sideband
Select the Sideband with Upper or Lower for channel
width 40MHz. [N band only]
