Wireless configuration
Mode
It shows wireless operation mode
Band
It shows the current wireless operating frequency.
SSID
It shows the SSID of this WLAN AP Router.
The SSID is the unique name of WLAN AP Router and
shared among its service area, so all device sat tempts to
join the same wireless network can identify it.
Channel Number
It shows the wireless channel connected currently.
Encryption
It shows the status of encryption function.
Associated Clients
It shows the number of connected clients (or stations,PCs).
BSSID
It shows the BSSID address of the WLAN AP Router.BSSID
is a six-byte address.
LAN configuration
IP Address
It shows the IP address of LAN interfaces of WLAN AP
Router.
Subnet Mask
It shows the IP subnet mask of LAN interfaces of WLAN AP
Router.
Default Gateway
It shows the default gateway setting for LAN interfaces
outgoing data packets.
DHCP Server
It shows the DHCP server is enabled or not.
MAC Address
It shows the MAC address of LAN interfaces of WLAN AP
Router.
WAN configuration
Attain IP Protocol
It shows how the WLAN AP Router gets the IP address. The
IP address can be set manually to a fixed one or set
dynamically by DHCP server or attain IP by PPPoE / PPTP
connection.
IP Address
It shows the IP address of WAN interface of WLAN AP
Router.
Subnet Mask
It shows the IP subnet mask of WAN interface of WLAN AP
Router.
Default Gateway
It shows the default gateway setting for WAN interface
outgoing data packets.
MAC Address
It shows the MAC address of WAN interface of WLAN AP
Router.
