Lithonia RSXF3 Flood LED
Rev. 12/13/18
Page 4 of 5
Performance Data
Lumen Ambient Temperature
(LAT) Multipliers
Use these factors to determine relative lumen output for
average ambient temperatures from 0-50°C (32-122°F).
Ambient Ambient Lumen Multiplier
0°C 32°F 1.05
5°C 41°F 1.04
10°C 50°F 1.03
15°C 59°F 1.02
20°C 68°F 1.01
25°C 77°F 1.00
30°C 86°F 0.99
35°C 95°F 0.98
40°C 104°F 0.97
45°C 113°F 0.96
50°C 122°F 0.95
Current (A)
Performance Package
System Watts (W) 120V 208V 240V 277V
347V 480V
P1
194W 1.61 0.92 0.80 0.69
0.56 0.40
P2
222W 1.85 1.06 0.92 0.80
0.63 0.45
P3
266W 2.22 1.27 1.10 0.95
0.76 0.55
P4
312W 2.60 1.49 1.29 1.11
0.89 0.64
Electrical Load
Values calculated according to IESNA TM-21-11 methodology and valid up to 40°C.
Operating Hours 50,000 75,000 100,000
Lumen Maintenance Factor >0.97 >0.95 >0.92
Projected LED Lumen Maintenance
Performance
Package
System Watts
Distribution.
Type
Field Angle Beam Angle
30K
(3000K, 70 CRI)
40K
(4000K, 70 CRI)
50K
(5000K, 70 CRI)
˚H ˚V ˚H ˚V Lumens LPW Max CD Lumens LPW Max CD Lumens LPW Max CD
P1 194W
AWFD 119 120 69 41 24,880 128 20,380 27,336 141 22,392 27,336 141 22,392
WFL 133 129 116 80 24,376 126 10,378 26,782 138 11,402 26,782 138 11,402
MFL 105 110 91 96 25,421 131 11,541 27,930 144 12,680 27,930 144 12,680
NFL 78 79 44 45 24,536 126 36,280 26,957 139 39,860 26,957 139 39,860
SP 48 48 27 27 23,747 122 75,642 26,091 134 83,109 26,091 134 83,109
NSP 42 44 19 21 24,165 125 127,593 26,550 137 140,186 26,550 137 140,186
P2 222W
AWFD 119 120 69 41 27,942 126 22,888 30,700 138 25,147 30,700 138 25,147
WFL 133 129 116 80 27,376 123 11,655 30,078 135 12,806 30,078 135 12,806
MFL 105 110 91 96 28,549 129 12,961 31,367 141 14,240 31,367 141 14,240
NFL 78 79 44 45 27,555 124 40,744 30,275 136 44,766 30,275 136 44,766
SP 48 48 27 27 26,670 120 84,953 29,302 132 93,337 29,302 132 93,337
NSP 42 44 19 21 27,139 122 143,296 29,817 134 157,436 29,817 134 157,436
P3 266W
AWFD 119 120 69 41 32,398 122 26,538 35,596 134 29,158 35,596 134 29,158
WFL 133 129 116 80 31,742 119 13,514 34,875 131 14,848 34,875 131 14,848
MFL 105 110 91 96 33,103 124 15,028 36,369 137 16,511 36,369 137 16,511
NFL 78 79 44 45 31,950 120 47,243 35,103 132 51,905 35,103 132 51,905
SP 48 48 27 27 30,923 116 98,500 33,975 128 108,222 33,975 128 108,222
NSP 42 44 19 21 31,467 118 166,148 34,572 130 182,543 34,572 130 182,543
P4 312W
AWFD 119 120 69 41 36,634 117 30,008 40,249 129 32,969 40,249 129 32,969
WFL 133 129 116 80 35,892 115 15,281 39,434 126 16,789 39,434 126 16,789
MFL 105 110 91 96 37,430 120 16,993 41,124 132 18,670 41,124 132 18,670
NFL 78 79 44 45 36,127 116 53,419 39,692 127 58,691 39,692 127 58,691
SP 48 48 27 27 34,966 112 111,379 38,416 123 122,368 38,416 123 122,368
NSP 42 44 19 21 35,581 114 187,870 39,092 125 206,409 39,092 125 206,409
Lumen Output
Lumen values are from photometric tests performed in accordance with IESNA LM-79-08. Data is considered to be representative of the configurations shown, within the tolerances allowed by Lighting
Facts. Contact factory for performance data on any configurations not shown here.
