Installation Guide

page 5

Photocell TIME/TEST switch

SETTING THE MOTION SENSOR

Note: Walk in a zigzag direction. Walking up to the motion

detector in a straight line may keep you in between detection

regions, and your light will not come on.

MOTION DETECTOR SET UP NOTES

If the lights stay on all the time: the sensitivity may be too high

or the motion detector head might be aimed too high. Try turning

the sensitivity down, and try aiming the head slightly lower. See

trouble shooting guide.

5. SET ON TIME

When you are satisﬁ ed with the area of coverage, slide the TIME/

TEST switch to the opposite end to take the motion detector out of

TEST mode. Now you can slide the switch to set the ON time. The

TIME setting switch will let you adjust the time that the light will

stay on after motion is detected from approx 1 to 10 minutes.

MANUAL OVERRIDE

To disable the motion sensor and keep the light continuously on

for the night, ﬂ ip the wall switch off for 3 seconds and then back

on.

To reset to Security mode, ﬂ ip the switch off again for 3 seconds

and then back on.

If you leave the light on all night it will automatically turn off at

dawn and reset to Security mode.

NOTE: If you get confused while switching modes, turn the power

at the breaker or walls witch off for one minute, then back on. After

the calibration time, the control will be in the Security mode.

IMPORTANT SEASONAL CHANGES:

The motion sensor works by sensing temperature changes across

its ﬁ eld of view. The closer the surrounding temperature is to a

person’s temperature the less sensitive the sensor will appear.

The greater the temperature difference, the more sensitive the

sensor will appear. The range may need to be readjusted with the

sensitivity dial as temperature changes for different seasons. This

is a normal part of the light sensor’s operation.

3 Seconds OFF then...

...back on
